Keep your trailer’s battery fully charged while on the move eliminating the need for unnecessary idling and reducing the dependence on mains power charging.
Designed with REDARCs tried and tested charging technology, the BCDC Trailer S features a DC-DC charger, an MPPT solar regulator and a smart battery isolator all packed into one compact, lightweight unit. The BCDC Trailer S has an input current limit specifically designed to allow you to connect directly through your trailer plug and existing vehicle wiring for easy installation.
TRAILER PLUG CONNECTION
Connect and charge directly through your trailer plug for easy installation into any typical trailer battery setup.
FUSE PROTECTION
Controls power to avoid overloading trailer plug connectors and protect your vehicle’s wiring and fuses.
SEAMLESS INTEGRATION
Compatible with all common battery makes and chemistries, including Standard Lead-Acid, Calcium, Gel, AGM and Lithium LiFeP04.
MAXIMISE BATTERY LIFE
Protect, maintain and extend your battery’s health during every use. Featuring an inbuilt isolator and three step charging process to ensure your batteries receive the right amount of power.
FEATURES:
- Combines a 12A charger and a 40A solar regulator into one unit for simplified power management.
- 40A solar regulator enhances off-grid adventures, enabling longer and more reliable power supply.
- 12A vehicle to trailer charger ensures batteries are charged and ready by the time you reach your destination.
- Built-in isolator prevents accidental discharge of the vehicle’s battery, ensuring safety and reliability.
- Protects vehicle wiring and fuses by efficiently managing current draw
Suitable for applications where the input current required to charge the trailer battery is drawn through the vehicle's towing harnesses and connectors.
The ideal battery charger for enclosed trailers - such as camper trailers, horse floats, mobile service vehicles & emergency vehicles.
Please note: The BCDC1212S Battery Charger is designed for installation within the vehicles cabin or in a similarly protected environment such as in a ute canopy, caravan or battery box.
| gtin_barcode | 9338628010318 |
|---|---|
| Battery Chemistry | Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only |
| Continuous Rating | 12A |
| Power Type - AC DC | DC TO DC |
| No Load Current | <100mA |
| Standby Current | <8mA |
| Weight | 0.8kg |
| height | 38mm |
| width | 119mm |
| depth | length | 165mm |
| Warranty | 2 Years |
| Connector Type | Bare wire |
| Input Voltage | 9 - 32V |
| Max. Charging Voltage | 15.3V |
| Max. Rated Output Current | 11A (12V vehicle) / 20A (24V vehicle) |
| Nominal Output Power | 147W (12V vehicle) / 294W (24V vehicle) |
| Input Fuse Rating | 15A to 23A (Not supplied) |
