BCDC Classic Under Bonnet 25A DC Battery Charger

SKU
BCDC1225D
A$679.00
In stock
Australian Made Premium Quality
Manufacturer Direct Suits Most Vehicles
Find Installer Buy In-Store
Product details
The REDARC BCDC1225D In-vehicle Dual Battery Charger is a 12 volt, 25A in-vehicle DC-DC battery charger designed to charge your secondary battery banks to 100% state of charge while on the move.*
OVERVIEW

The REDARC BCDC1225D under bonnet Battery Charger is a 12V 25A DC to DC battery charger, capable of high performance in engine bay installations, potted to survive and thrive against heat, water and dust.

Featuring a Maximum Power Point Tracking (MPPT) solar regulator, the BCDC1225D Classic will charge from both solar and the alternator simultaneously. And, with built-in 'Green Power Priority' it will select solar charging first, meaning less load on the alternator.

Suitable for 12 or 24-volt vehicle systems, the unit will also work with either standard or variable/smart alternators.

The BCDC1225D features the same patented charging profiles as it’s predecessor along with a new lithium charging profile making the unit suitable for charging AGM, Gel, Standard Lead Acid, Calcium and LiFePO4 batteries, perfect for pairing with a REDARC Lithium battery.

For most applications, the BCDC1225D is suitable for battery bank sizes of 75-200AH. For higher capacity needs of over 200AH, REDARC recommends the BCDC1240D

Proven and Tested

The award-winning technology in the BCDC has been independently verified and tested to ensure battery life is maximised, charging your battery to a proven 100%.

Built in Australia and tested for our unique conditions, the DC to DC battery charger will work in the extreme heat of the Simpson Desert, up to 80°C and can handle deep water crossings at Cape York – water, dust and vibration are no match for this charger.

If you’re heading out into the bush and want to get there and back again safely – you can trust REDARC.

Features
  • Separate DC and solar charging inputs
  • Maximises the performance and life of your auxiliary battery
  • Simultaneous DC and solar charging with Green Power Priority
  • Suits 12V/24V standard and variable voltage/smart alternators
  • Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries
  • Suitable for use on vehicles with conventional alternator charging systems

Mounting Brackets

In addition to the use of quality fuse kits, REDARC offer a range of vehicle-specific mounting brackets for our BCDC DC-DC Charger range. The 304 stainless steel bracket allows installation into the front of the vehicle for cooler airflow, ensuring optimal performance. They have been designed to fit existing mounting points in the vehicle. Click here to view the range


Not sure what dual battery system is best for your vehicle? Let Shaun Whale explain more.

Specifications
More Information
Warranty 2 Years
gtin_barcode 9338628004348
brand REDARC
Battery Chemistry Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only
Power Type - AC DC DC TO DC
Nominal Output Power 375W
Input Fuse Rating 40A (Not supplied) REDARC FK40 recommended
Solar Switch On Voltage 9V
Suitable For 12V Systems Yes
Suitable For 24V Systems Yes
Solar Input Voltage 9 - 32V
MPPT Solar Regulator Yes
Cabin/ Canopy Install Yes
No Load Current <100mA
Trailer Install Yes
Engine Bay Install Yes
Max. Charging Voltage 15.3V
Output Fuse Rating 40A (Not supplied) REDARC FK40 recommended
Operating Temperature -10°C to 80°C
Output Voltage 12V DC
Max. Rated Output Current 25A
Input Voltage 9 - 32V
Standby Current <8mA
Connector Type Bare wire
Weight 1 kg
width 120 mm
height 37 mm
depth | length 165 mm
